Automatic high speed heat shrink packaging machine food and medicine electrical switch POF film packaging machine
Main technical parameters
Max Flim size | ≤590mm | ||||||
Model | 120 | 150 | 180 | 210 | 240 | ||
Packing size | L : | L:60mm-320mm | L:100mm-450mm | L:150mm-530mm | L:180mm-600mm | L:210mm-650mm | |
W: | w:10mm-200mm | w:10mm-200mm | w:10mm-200mm | w:10mm-200mm | w:10mm-250mm | ||
H: | H:5mm-35mm | H:35mm-70mm | H:65mm-100mm | H:80mm-130mm | H:100mm-150mm | ||
Packing speed | 30-150 packs / min | 30-150 packs / min | 30-135 packs / min | 30-100 packs / min | 30-80 packs / min | ||
Flim type | PVC;POF; | ||||||
Power consumption | Packaging machine:4.75KW;Shrinking machine13.5KW | ||||||
Power supply |
Host :220V,50HZ/60HZ;Shrinking machine:380V,50HZ/60HZ |
||||||
Envelop dimensions | 4800x1170x1500mm | ||||||
Shrinking machine |
External dimensions :2600x600x1700mm |
The hearth:2300*250*200mm | |||||
Weight |
Host :760KG |
Shrinking machine:380KG |
Performance characteristics
1. Color touch screen control system, using three servo motor drive, the whole machine is easy to operate, high stability, high packaging efficiency, low failure rate, bag length, speed and temperature can be individually adjusted, easy to operate and accurate.
2. Anti-cutting safety clutch device, do not damage the packaging.
3. High sensitivity photoelectric eye color mark tracking, mathematical input sealing cut position, make sealing cut position more accurate.
4. Temperature Independent PID control, more suitable for a variety of coating materials.
5. Positioning stop function, non-stick knife, do not waste film.
6. Simple transmission system, more reliable work, more convenient maintenance.
7. Switch to automatic product reversal, restart directly after boot for easy operation.
8. Increase the waste recovery device, make packaging more beautiful, than the traditional folding film packaging machine save material about 20% -30% .
9. Can be equipped with a printer or inkjet printer, no need to use manual.
10. With motor brake control, the equipment is responsive.
11. High efficient double temperature zone, high efficient hot air circulation, automatic temperature control, ensure shrinkage quality.
